UNMATCHED VERSATILITY

BEYOND THE TYPICAL HEAVY MATERIAL HANDLER

Whether you are carrying light or heavy loads, the maneuverability of the Payloader Series is second to none. Payloaders can carry up to 5,200 pounds, tow up to 14,000 pounds and travel up to 17 mph while offering exceptional maneuverability and access to places that larger burden carriers just can't go. We use the same chassis for all our different weight classes which means durability and dependability will not be an issue.

2 Bed Lengths - 62" or 76"

12 gauge steel smooth plate body

10 gauge steel support sections

Front and rear steel bumpers

Best in class load capacities

Great platform for customization

Dual head and tail lights

Overview

With a slim profile and exceptional turning radius, the Payloader replaces dangerous forklifts to deliver materials through tight spaces – all while improving visibility and overall safety. With an optional rated towing capacity of seven tons, and a range of carrying capacities from 2,400 to 5,200 pounds, the Payloader can handle all kinds of loads with optional extra seating and carrying capacity for special applications and extra heavy requirements. Pure electric power and the same steel chassis used throughout our vehicle line offer an impressive level of access, range, and ruggedness for any task it's put to.

  • TOTAL WAREHOUSE has an massive inventory of New and Used Columbia vehicles available for Sale, Rent, and Lease.

Still not convinced?

Let us help you decide.

The warehouse experts at TOTAL WAREHOUSE have decades of experience with every type of industry and operation. We know the exact equipment and storage system combination needed to increase your output. Give us a call and let's grow your business together.

Contact us

Handle any load

improved visibility and safety

    specifications

    Step Height16.5"
    Load Bed Height29"
    Ground Clearance4.5"
    Max Speed Forwardup to 14 MPH
    Turning Radius Curb to Curb264"
    turning radius intersecting aisle92"
    Range30 Miles
    Vehicle Weight1690 - 1850 LBS
    Rated Capacityup to 5,200 LBS
    Towing Capacityup to 14,000 LBS
    MotorNEMA Class H Temp-rated
    horsepowerup to 17.3 HP @ 1750 RPM
    Batterieseight 6-volt. heavy duty, 232 amp hour deep cycle
    chargerBuilt in, micro-processor control, fully sealed
    controller typeProgrammable, solid state, reduced speed reverse
    controller rating400 amp
    motor breaking modeRegenerative and pedal proportional braking with top speed limiting
    directional controlDash-mounted safety directional keyswitch

    Before / After

    Unbelievable warehouse transformations

    Lease Rates

    We can deliver the Payloader/Burden carrier today

    Daily

    Starting At

    request quote

    production without liability

    24/7 availability

    • Plenty in stock at all TW locations
    • WE DELIVER!

    May vary upon evaluation

    Reserve

    Weekly

    Starting At

    request quote

    Why buy when you can rent?

    24/7 availability

    • Plenty in stock at all TW locations
    • WE DELIVER!

    May vary upon evaluation

    Reserve

    Monthly

    Starting At

    request quote

    Best value for savings

    24/7 availability

    • Plenty in stock at all TW locations
    • WE DELIVER!

    May vary upon evaluation

    Reserve

    Long Term

    Starting At

    request quote

    A plan built custom to your exact needs

    24/7 availability

    • Plenty in stock at all TW locations
    • WE DELIVER!

    May vary upon evaluation

    Reserve
